Combine Waterjet and Plasma in One Machine

We specialize in combining plasma and waterjet cutting in the same CNC table system to save cost and provide more cost effective cutting solutions.

  • How does plasma cutting work?
  • FAQ of plasma cutting machine.
  • Plasma cutting speed reference.
  • Spare parts of plasma cutter.
  • Plasma Cutting Machine Models and Specification

    • plasma cutting machine



















    Waterjet and Plasma Cutting Machine -- Model PM1000

    PM1000 plasma cutting machine can be installed with CNC Waterjet cutting tables of various sizes to be combined CNC waterjet and plasma cutting system.

    combination plasma cutting machine    + plasma cutting machine    + plasma cutting machine
    Plasma 1000       Waterjet                 Cutting table
    Materials to be cut All metals (mild steel, stainless steel, aluminum, titanium, copper etc)
    and non-metal (marble, granite, glass, ceramic, plastic, rubber etc).
    Application Plasma:  metal thickness of 15mm or less
    Waterjet:  all other materials.
    Waterjet specification
    Pump type reciprocal intensifier
    Pump power rating 50HP, 37kw,
    3 phase, 220V or 380VAC, 50/60 Hz.
    Max output pressure 55000 psi (3800 bar)
    Plasma specification
    Max separation thickness 25mm
    Max smooth cutting thickness 16mm
    Rated input power 3 phase, 380VAC, 50Hz, 18kw, 27A.
    Plasma power type Full bridge IGBT inverter module
    Rated output voltage 140-160VDC
    Rated output current Continuously adjust between 20-100Amps.
    Cooling type Air flow
    Gas pressure 0.4-0.6MPa -- Air, O2, N2
    CNC cutting table 1300x1300mm, 1300x2500mm, 2000x3000mm, 3000x6000mm, 3000x12000mm, 5000x15000mm.....
    plasma cutting machine        plasma cutting machine
    CNC plasma cutting machine models: PM100A1313H, PM100A1325H, PM100A1632H, .......... PM100A50150H





    plasma cutting machine



















    Waterjet and Plasma Cutting Machine -- Model PM2000

    PM2000 plasma cutting machine can be installed with CNC Waterjet cutting tables of various sizes to be combined CNC waterjet and plasma cutting system.

    combination plasma cutting machine    + plasma cutting machine    + plasma cutting machine
    Plasma 2000       Waterjet                 Cutting table
    Materials to be cut All metals (mild steel, stainless steel, aluminum, titanium, copper etc)
    and non-metal (marble, granite, glass, ceramic, plastic, rubber etc).
    Application Plasma:  metal thickness of 25mm or less
    Waterjet:  all other materials.
    Waterjet specification
    Pump type reciprocal intensifier
    Pump power rating 50HP, 37kw,
    3 phase, 220V or 380VAC, 50/60 Hz.
    Max output pressure 55000 psi (3800 bar)
    Plasma specification
    Max separation thickness 35mm
    Max smooth cutting thickness 28mm
    Rated input power 3 phase, 380VAC, 50Hz, 38kw, 57A.
    Plasma power type Full bridge IGBT inverter module
    Rated output voltage 140-160VDC
    Rated output current Continuously adjust between 40-180Amps.
    Cooling type Water cooling
    Gas pressure 0.4-0.6MPa -- Air, O2, N2
    CNC cutting table 1300x1300mm, 1300x2500mm, 2000x3000mm, 3000x6000mm, 3000x12000mm, 5000x15000mm.....
    plasma cutting machine       plasma cutting machine
    CNC plasma cutting machine models: PM200A1313H, PM200A1325H, PM200A1632H, .......... PM200A50150H





    plasma cutting machine



















    Waterjet and Plasma Cutting Machine -- Model PM4000

    PM4000 plasma cutting machine can be installed with CNC Waterjet cutting tables of various sizes to be combined CNC waterjet and plasma cutting system.

    combination plasma cutting machine    + plasma cutting machine    + plasma cutting machine
    Plasma 4000       Waterjet                 Cutting table
    Materials to be cut All metals (mild steel, stainless steel, aluminum, titanium, copper etc)
    and non-metal (marble, granite, glass, ceramic, plastic, rubber etc).
    Application Plasma:  metal thickness of 35mm or less
    Waterjet:  all other materials.
    Waterjet specification
    Pump type reciprocal intensifier
    Pump power rating 50HP, 37kw,
    3 phase, 220V or 380VAC, 50/60 Hz.
    Max output pressure 55000 psi (3800 bar)
    Plasma specification
    Max separation thickness 65mm
    Max smooth cutting thickness 40mm
    Rated input power 3 phase, 380VAC, 50Hz, 73kw, 110A.
    Plasma power type Full bridge IGBT inverter module
    Rated output voltage 140-160VDC
    Rated output current Continuously adjust between 80-340Amps.
    Cooling type Water cooling
    Gas pressure 0.4-0.6MPa -- Air, O2, N2
    CNC cutting table 1300x1300mm, 1300x2500mm, 2000x3000mm, 3000x6000mm, 3000x12000mm, 5000x15000mm.....
    plasma cutting machine       plasma cutting machine
    CNC plasma cutting machine models: PM400A1313H, PM400A1325H, PM400A1632H, .......... PM400A50150H
